DISPLAY
Size
86"
Resolution
3840 X 2160 (UHD)
DISPLAY
Backlight Unit Type
Direct
Brightness
330 nits
DISPLAY
Dynamic Contrast Ratio<br>(Dynamic MCI (Hz))
1,000,000:1
DISPLAY
Static (Panel) Contrast Ratio
1200:1
Response Time (G to G)
5 ms
Refresh Rate
120 Hz
DISPLAY
Life Span
30,000 hrs
DISPLAY
HDR_HDR 10 Pro
Yes
HDR_HLG
Yes
AUDIO
Built-in Speakers
2.0 channel, 10W + 10W
AUDIO
LG Sound Sync
Yes (Bluetooth Required)
BROADCASTING
Broadcasting System
ATSC, Clear QAM, Analog NTSC
Global IPTV Support
Yes
SMART FEATURES
Smart Home (Launcher Bar)
Yes
SMART FEATURES
Quick Access
Yes
SMART FEATURES
Web Browser
Yes
Pre-loaded App
YouTube
SDP Server compatibility
Yes
SW Clock (World Clock / Alarm)
Yes
SMART FEATURES
Mood Display
Yes
SMART FEATURES
SoftAP
Yes
Wi-Fi
802.11ac
Screen Share (Miracast)
Yes
SMART FEATURES
Smart Share
Yes
LG ThinQ App
Yes
SMART FEATURES
DIAL
Yes
Bluetooth Audio Playback
Yes
Mobile Connection Overlay
Yes
OTHER FEATURES
HDMI-ARC
ARC, HDMI2
USB Cloning
Yes
WOL
Yes
SNMP
Yes
OTHER FEATURES
Self Diagnostics (USB)
Yes
SI Compatible Protocol
TVLink Tuner
OTHER FEATURES
HTNG-CEC
Yes
Simplink (HDMI-CEC)
1.4
IR Out
RS-232C
Multi-code IR
Yes
Hotel Mode / PDM / Installer Menu
Yes
Lock mode
Yes (Limited)
Port Block
Yes
Welcome Screen (Splash Image)
Yes
Insert Image
Yes
IP Channel Manager
Yes
OTHER FEATURES
External Speaker Out
Int / Fixed, 3.5mm, Stereo, Single ended Type(GND,L+,R+), 2W with 8Ω
OTHER FEATURES
RJP (remote jack pack) Compatibility
Teleadapt/Guestlink (HDMI CEC)
Moving Picture Playback (SD/HD/Plus HD)
Yes
Auto Off / Sleep Timer
Yes / Yes
Energy Saving mode
Yes
Motion Eye Care
Yes
OTHER FEATURES
Crestron Certi. Compatibility
Yes
DPM (Digital Power Management)
Yes
Time scheduler
Yes
RTC (Real Time Clock)
Yes
OTHER FEATURES
NTP sync timer
Yes
BEACON
Yes
OTHER FEATURES
Embedded CM (Contents Manager)
Yes
Embedded GM (Group Manager)
Yes
SuperSign Control / Control Plus
Yes / Yes
SuperSign CMS(Premium)
Yes
Simple Editor
Yes
INTERFACES
HDMI In
3 (v2.0)
RS-232C
3.5mm Stereo Jack
Service Only
3.5mm Stereo Jack
INTERFACES
USB 2.0
1
INTERFACES
RF In
1
Optical Digital Audio Out
1
External Speaker Out
3.5mm Stereo Jack
INTERFACES
RJ45 (LAN)
1
MECHANICAL
Stand Type
20Y 2Pole
Front Color
Blue
VESA Compatible
600 x 400
MECHANICAL
Kensington Lock
Yes
MECHANICAL
Weight without Stand
99.6 lbs / 45.2 kg
Weight with Stand
101.2 lbs / 45.9 kg
MECHANICAL
Shipping Weight
128.8 lbs / 58.4 kg
MECHANICAL
Dimensions without Stand
75.9 x 43.5 x 2.4 in<br>1927 x 1104 x 59.9 mm
Dimensions with Stand
75.9 x 45.9 x 14.3 in<br>1927 x 1167 x 362 mm
Dimensions in Shipping
83.3 x 47.8 x 9.0 in<br>2115 x 1215 x 228 mm
Bezel Width (L/R/U/B): On Bezel
15.9 / 15.9 / 15.9 / 19.9 mm
Bezel Width (L/R/U/B): Off Bezel
6.9 / 6.9 / 6.9 / 18.4 mm
POWER
Power Supply (Voltage, Hz)
120 Vac, 50/60 Hz
Power Consumption (Max)
339 W
Power Consumption (Typ)
313 W
Standby Power Consumption
Less than 0.5W
WARRANTY & OTHER
Standards
UL
EMC Certification
FCC
Environmental
EPEAT, ISTA6
Accessories
L-Con Remote Control, Power Cable (2m, Attached), Optional Chromecast Anti-theft Accessory
